UNS N06200 — The most versatile C-type — copper-bearing for sulfuric service on top of full C-22 capability.
Nominal published values for the annealed condition. Certified heat lots ship with actual MTC values.
| Property | Value |
|---|---|
| Density | 8.5 g/cm³ |
| Min. yield strength (annealed) | 360 MPa |
| Min. tensile strength (annealed) | 790 MPa |
| Max service temperature | — |
| Nominal chemistry | Ni ~59% · Cr ~23% · Mo ~16% · Cu ~1.6% |
0.3 – 100 mm · up to 2500 mm · HR · 2B · BA · No.4 · mirror · laser · plasma · waterjet
Full sheets & plates page →ASTM B443 · ASTM B168 · ASTM B409 · ASTM B424 · ASTM B575 · ASTM B162 · ASTM B906
Confirm your standard →Pipe, fittings, bar, sheet, wire and forgings — consolidated into one PO with matching heats.
Hastelloy C-2000 grade hub →Standard sizes per the sheets & plates range (see supply range above) are stocked or on a frequent smelting schedule for Hastelloy C-2000. Non-standard dimensions are made to order — confirm with your inquiry.
Every heat ships with EN 10204 3.1 MTC: ladle + product chemistry, mechanical results, dimensional data and heat number. Third-party witnessed 3.2 available on request.
Typical uses: Mixed-acid plants; Pharmaceutical processing. If your medium, temperature or pressure differs, our metallurgists verify grade selection free of charge before quoting.
Dimensions, quantity, standard — that is all we need. A named metallurgist replies with pricing, lead time and MTC sample.
